Archive for the 'Repairing' Category

Electrickery

Sunday, March 22nd, 2009

This was going to be the weekend I took the Z750 in for it’s MOT and got ready to ride again. The Kawasaki had other plans though. Running through the lights to make sure they all worked, and my previous temporary repair to the high beam/low beam switch gave up. The screw replacing the original thumb push just broke out of the internal switchgear. So no high beam.

Luckily when Big Al got his Z750 he replaced both handlebar switch controls, so there was a spare in the garage. The problem was the wires had been cut (not by Al I hasten to add) so the loom would need connecting in some way. I decided that soldering was the best course of action.

I removed the left hand control switches and cut back the wiring to a point I could access easily, and that had a previous taped repair anyway. I then mounted the “new “ set of control switches, and put the cable through to cut to match the existing bit. So far so good.

Out came the trusty soldering iron, and solder. The first wire was matched to its new partner, and both were tinned and then held together and the iron applied to melt the solder together. Success. Cover the exposed wires and on to the next. The second one also went well. It’s after that things become difficult.

The 2 previously soldered wires now have a tendency to push the others away from each other so twisting and bending becomes the only choice. 3rd and 4th wires done, the 5th wire becomes difficult to position, solder and hold all with just two hands. If you ever want to learn new swear words and new and innovative sentences containing swear words, just turn up when someone is in this predicament. The burnt fingertips and many badly soldered joints which have to be redone are not good for the nerves.

By wire number 7 the whole world seems to have turned against you, and everything nearby is in danger of a kick or getting thrown if it gets in the way. Add some wind cooling the solder rapidly and things get real ugly.

Anyway in the end all 8 wires are soldered, 4 fingertips are burnt and none of the neighbours will let their kids anywhere near in case they pick up some bad words. But joy of joys it all works and now all is right with the world once more. Peace is restored to the Sabbath.

So next time it’s the MOT test. Be afraid…..

Cats, Covers and Carburettors

Sunday, March 15th, 2009

I finally decided it was time to get to work on the Z750 twin and maybe get the mot done. I removed the cover and looked at the bike and decided I should replace the torn seat cover as I have had one sitting around which was made by another Z750 twin owner (Thanks Phil).

So I removed the 3 securing bolts and took off the seat. Removed the dangling trim, and prised up the clips holding the cover in place. Luckily the base is in good condition, a rarity on Japanese bikes of this vintage, but this was so I was happy. I covered the stickers underneath the seat and then painted the base to tidy it up.

After waiting for the paint to dry which should take 24 hours according to the tin but in this case was less than 10 minutes, I started to fit the new cover. Impatient? Me? So I pulled it tight across the foam, and started pulling it over the sharp pointy clips at the front. With the help of my wife I worked along one side, then the other pulling it very tight and pushing th4e foam down to ensure a nice smooth crease free finish.

Eventually it was all pulled on, and as we’d gone round we’d also put on a piece of black trim my dad had picked up from an autojumble which helped keep the cover in place and finish off the edge nicely. A little trim and the seat was ready to refit complete with fingerprints in the soft paint on the underside.

PICT0206

Then I made the decision to start the Kawasaki Twin and a couple of kicks saw it breathe fire once again. But only briefly before it coughed on one cylinder, and then the remaining one gave up trying to drag its dead brother. The last excursion fault had reared its head again, but I had an idea it was one of the carbs and they’d need removing and stripping. Impatience and laziness fought that one out, and laziness won. So I put the cover back on.

One week later and I had worked up enthusiasm to remove the carburettors, which involved removing the side panels, petrol tank and 4 hose clamps. Wriggled out the carbs and removed the cables so I could work on them.

Starting with a diaphragm check, I removed the tops of the carbs and held up the diaphragms to the light and tugged lightly. Both were fine. I stripped the carb bowls off, and checked the floats, and needles and blew in the pipes while holding the floats up to check they were shutting off, and opening with the float movement. All ok. A quick clean through the venturi (holes to you and me) with some cleaner spray, and clean up the inaccessible parts with some more spray and it was time to refit them.

After the carbs were back on, I put the tank and covers back and got ready to start the bike again. That’s where the cats come into it. On the new seat cover I noticed some small pin pricks, and claw marks where the cats have been using the bike as a resting place and clawing the the seat to pull themselves up on their preferred spot. GRRRRRR. Anybody need a tennis racquet restrung, I know where to get some catgut. Also I feel so much less sympathy for Tom when Jerry hits him with a frying pan or other blunt object on Cartoon Network now.

Luckily the Z750 twin started on the second kick, and ran perfectly for ten minutes or so at various throttle settings. Hopefully it can now be ridden for its mot in the near future ready to be taxed and ridden again in 2009. Watch this space…

Waiting For Spring

Saturday, February 21st, 2009

The Z750 has been rested up for the winter. Last year I paid the money to tax it all year round, but found that the winter was cold, and colder on a bike than in the car, who’d have thought it?

So this year I saved the money and took the bike off the road to carry out a few repairs etc on it while it was stood up. So far since October till now in mid February I have erm  well left the old Kawasaki covered up nice and warm and not looked under the cover since. But I did think about removing the seat to fit a new cover. I also considered cleaning and repainting some parts. But none of it happened.

So there you have it then, 4 months of absolutely nothing happening summed up into 3 paragraphs. Probably could have stretched it a bit and said how I’d also given some consideration to removing the carburettors for a good check over and clean out, but that would have been pushing it as the thought didn’t cross my mind until just a moment ago when I was trying to come up with something to write.

Soon though it will go for this years MOT and be taxed and ridden again, and I’m considering buying slim and fit Al’s Z750 off him if I can raise the funds. So look in again soon to see what’s happening.

Z750 B1 Gets Minor Routine Maintenance

Monday, May 5th, 2008

It’s a bank holiday weekend in the UK so consequently it’s cloudy, showery and changeable on the weather front. So as I won’t ride in the possibility of rain I decided to do some maintenance on the Z750 twin. Nothing too drastic, some minor lubrication and simple routine stuff was all I had in mind, about ten minutes of fettling in other words.

Firstly I decided to grease the rear swing arm bushes, which Kawasaki made provision for on the Z750 B1 by putting in a grease nipple on the swing arm. I retrieved the grease gun from my company van, and found it empty as I had left it. Located the grease cartridges and changed it. That sounds easy enough as I write it here, but it took 20 minutes to find the grease cartridges and to coax it into the grease gun which didn’t seem to want to screw back together afterwards.

After some persuasion and naughty words (the wife and kids were out so it was ok to use them instead of words like “oh bother” and “deary me”) I was ready to hit the grease nipple with the nozzle. Kawasaki saw fit to give us a grease point, but not to make it accessible. You can see it between the frame and the rear brake line I have ringed it on this blurred picture for you

Z750 twin B1 swingarm grease nipple location

It even looks accessible until you push the grease gun nozzle in the gap. I tried several different ways, and a lot of the swear words I knew before getting the nozzle on the nipple and pumping grease on the swing arm at the same time as into the nipple. I spent the next ten minutes with a bit of stick and rag cleaning the excess grease off the swing arm to prevent it falling on the tyre while I am riding one day.

With the swing arm having got as much grease as my blood pressure was going to allow before breaking out of several veins in my brain, I set about the simple task of lubricating the chain. Have you ever noticed how the nozzles of cans of spray (such as the chain spray I was about to use) have a habit of going missing?

Having located the chain spray nozzle I realised I was unable to spin the rear wheel to access the entire chain. I had to get the bike higher in order to get the rear wheel off the ground. I found a piece of wood, placed it carefully under the centre stand and heaved the bike up the extra height. The wheel spun freely and I lubricated the chain. It has been said at times I work on the wrong side of safety, decide for yourself now :-(

dangerous motorbike centre stand on wood

I noticed the wood had moved as I was about to take the bike back down off the stand, it didn’t fall so it must have been safe like that right? You can comment below if you’d like to :-)

By now the 10 minute routine lube jobs had run into an hour and a half, and I decided I’d had enough for one day. It is after all a holiday so I am going to rest now.

Time For An Oil Change

Sunday, February 10th, 2008

Today I decided it was time the poor old Kawasaki’s engine had some fresh oil. It was last changed when I first bought the bike and it has done some work since then, and the oil was only going to be in for the initial start up, and a few miles before it got changed to kind of flush the lubrication system out.

The oil change has been on the agenda for a while, but today I finally got out the washing up bowl (don’t tell the wife) to drain the oil into and got underneath with the spanner and let out the old lubricant. It wasn’t in bad condition really, but it’s gone now to be recycled, and the new oil is in.

I just couldn’t be arsed to change the oil filter though as that meant removing footrests, gear levers, engine side covers and more faffing around. That’s a job for the next Z750 twins next oil change, when it may also get some other new parts, but at least the oil is good for a few more miles of engine protection duties.

All Quiet

Sunday, December 9th, 2007

It’s that time of year, cold, wet and miserable, when for me anyway motorcycling loses its appeal somewhat. I know the ruffty tuffty biker types will be making faces and pointing at me for that remark, but laugh away, I’m staying warm and dry for now.

So with the absence of any Z750 activity there has been a dearth of posts, as I’m sure people reading a site about Z750 twins won’t be interested in reading about me sitting by the fire watching telly. There is a little news though.

I bought some motorcycle trouses from Ebay to wear in case of a dry day even if it’s a bit cold during the winter. Problem was the manufacturer got the sizing wrong, and the xl just doesn’t fit my lithe body. I mean it can’t be me can it?
Well I have lost a stone and a half since I bought them, and they do button up now so a few more pounds should see me in them :)

On another note, the Lonesome Twin Forum went down, and unfortunately this has become a common ocurrence meaning the Z750 twin owners of the world lose contact. So some of the members have got together and started the Z750 Twin Forum to keep us in touch. Why not visit and see who’s there?

So that’s about all for now, till next time, Take Care out there.

Taxation Paid

Sunday, November 4th, 2007

Taxation

I paid up for a whole years tax on the 31st October so the Z750 is on the road for at least 12 months more. That’s tax, MOT and insurance paid for a while now anyway :-)
Next to put some of our liquid gold priced petrol in the bike.

A Great Start To A Weekend

Saturday, October 27th, 2007

A Great Start To A Weekend

What better way to start the weekend than to get on a Kawasaki?
How about getting on a Kawasaki Z750?
Or even better getting on your Kawasaki Z750 twin?
Going a step further how about getting on a Z750 Twin riding to the mot station and despite having mot’d 3000 bikes in the past 12 months, the mot tester remembers every detail of last years mot?

Yep this year the mot tester remarked on the bikes failure last year and immediately checked the forks to see if they were parallel, which they were with the new yokes. Thoroughly tested brakes, bearings spokes, headstock, forks and everything else for the mot and then wrote out the new mot certificate so it’s safe for road use for another year.

Next the road tax is due at the end of October but that’s days away so no need to worry about that yet.

On The Road Again

Friday, October 26th, 2007

After finishing work today I dragged my unwilling carcass out into the cold to finish putting the Z750 twin back together. I tightened the steering clamp mounts, and refitted the newly painted clock assembly.

Then I polished up the front mudguard and put it and the cable and brake hose guides back on the forks. It all looks rather nice as my wife has painted the fork sliders and a few other parts.

Next came the hard work, I got the missus to hold down the back of the kawasaki, while I pulled up the forks to fit the front wheel in place. 3 attempts later and the wheel was in, then I refitted the clamps, one of which had been held in by a bolt instead of the stud it should have. I removed a stud from some old forks using two nuts and loctited it into the forks I’m using.

Next I refitted the front brake calliper after smearing the back of the pads, and the slider bolts with copper grease as they used to squeal badly. The pads are worn but servicable for now, so I will replace them in the near future. Once the calliper was bled out and the reservoir topped up, the brake was back to its old self, probably not the best thing, but apparently that’s just how they are on these old Z750’s - crap.

Another major drama is refitting all the wiring into the headlight bowl, but while it was all exposed I repaired some old bodges which had been done to the wiring harness. I refitted the headlight, and it’s adjuster bracket, then tested all the lights and run the bike up, all worked ok.

Finally a quick last check of all the bolts to make sure they’re tight and then a road test. The steering never felt heavy before, but it feels lighter now, either psychological, or the taper bearings made a real difference, not sure yet. The front end all seems to be better aligned, so that’s made it worth while.

Finally, back on the stand for another check around the bolts and clamps and check for play in the headstock bearings now they have settled a bit. All good, so tomorrow it’s in for its MOT test, watch this space.

Am I On A Roll Or What?

Wednesday, October 24th, 2007

Am I On A Roll Or What?

Tonight, I got home from work to find the new taper bearings for my Z750 twins’ yokes had arrived. So all enthusiastic like I ran out and knocked out the old ball bearing races. Not as easy as it sounds in writing, I had to use a lot of brute force and even snapped one race in two getting it out.

I drifted the new bearing shells into the headstock and the bottom race onto the bottom yoke shaft. Packed them all with grease and fitted the replacement yokes into the headstock. Looked nice, so I adjusted the bearings and fitted the top yoke and handlebars.

I then trial fitted the forks, and with the first one in the second slid nicely and squarely into its own holes. So much easier then the first time I fitted forks to this Z750 as that time they had to be forced into position.

I then slid the forks out and cleaned up the chrome surrounds which hold the headlight and indicators. I placed them in the yokes and went to refit the forks. The left hand fork no longer slid nicely in place. I removed the surrounds and cleaned the insides with emery cloth and pushed them over the forks off the bike. I then greased the insides and refitted them to the bike. This time all slid into place with minimal force.

I retightened the lower yoke clamps on the forks and called that it for the day. I am spending some time cleaning and painting the parts which are inaccessible when it’s all together or rather my wife is doing it for me. Once they are painted and dry I will refit the rest of the front end and see how it all looks then.

All in all though another great evenings work.
